Continuous Gas Analyzer

Name: Continuous Gas Analyzer
Brand: HNL SYSTEMS PVT. LTD.
Price: 850000 INR
Availability: InStock

Price 850000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Continuous Gas Analyzer Specification

Operate Method
Extraction Type

Display Type
Digital (LCD)

Temperature
5-45°C

Equipment Type
Continuous Gas Analyzer

Operating Voltage
220V AC

Accuracy
±1% of FS

Mounting Type
Panel/Wall Mounted

Resolution
1 ppm

Test Range
0-100% (Depending on Gas Type)

Port Size
1/4 NPT

Measuring Range
0-1000 ppm (Gas Dependent)

Power Supply
220V AC, 50Hz

Application
Industrial Gas Monitoring, Environmental Monitoring, Process Control

Power
230 V AC , 50 Hz Volt (v)

Features
Continuous Monitoring, Auto Calibration, Real-time Data

Automation Grade
Automatic

Gas Pressure
0.2 - 0.5 MPa

Humidity
0-95% RH non-condensing

Interface Type
RS232/RS485

Frequency
50 Hz

Response Time
<30 seconds

Usage
Industrial and Laboratory

Machine Weight
Approx. 30 kg

Control Mode
Microprocessor Based

Output Signal
4-20 mA analog, digital output

Protection Class
IP54

Detected Gases
O2, CO, CO2, NOx, SO2, and other selectable gases

Warm-up Time
15 minutes

Sampling Mode
Extractive/Non-Dispersive

Calibration Interval
6-12 months (user adjustable)

Enclosure Material
Powder Coated Metal

Data Logging
Internal Memory with USB Export

Continuous Gas Analyzer Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Telegraphic Transfer (T/T)

Supply Ability
1 Piece Per Month

Delivery Time
1 Months

Main Export Market(s)
Eastern Europe, Middle East, Africa, Western Europe, Asia

Main Domestic Market
All India

Certifications
CE,TUV

About Continuous Gas Analyzer

Our engineers and technicians have years of industry experience for developing a qualitative range of Continuous Gas Analyzer. Under the stern guidance of our team, this is manufactured with use of the finest quality materials. This has applications in automobile, diesel, locomotive, and catalyst exhaust monitoring. It provides precise, reliable continuous analysis of process gas down to ultra low ppm levels. As per the variegated needs of our clients, we provide this Continuous Gas Analyzer at pocket-friendly prices.

Features of Continuous Gas Analyzer :

Hassle-free operation
Excellent functionality
Low maintenance

Specifications of Continuous Gas Analyzer :

Sensor & sampling: Gas Ranges & Application dependent
Gas: O2 , CO , CO2 , SOX , NOX , CH4 , NH3 , H2S , HC , Cl2 , HF , CS2 , H2 , VOC , HCl
Display: Digital Standard LED optional alphanumeric display
Power Supply: 230 V AC , 50 Hz
Ambient Temp: 0-50 C
Enclosure: Aluminum casing (power coated) for indoor application
Mounting: Standard: 19" Rack mounted
Optional: Flush on Panel/Tabletop
Warm up time: Analysis Detector dependent
Output (Optional): 4-20mA
Alarms: Two Level (selectable range)
Sample Gas Condition: Temp:0-50C, Pressure: Less than 1.5Kg/cm, The gas should be dry& clean. Other than this suitable sample, conditioning system is required.
Calibration: Manual, On command in microprocessor based system.

Comprehensive Gas Detection

This analyzer measures a wide range of gases such as O2, CO, CO2, NOx, SO2, and more, making it adaptable to varying monitoring requirements. The selectable detection capability supports both environmental and industrial process applications, ensuring flexible deployment wherever precise gas measurement is critical.

Efficient Data Management and Connectivity

With internal memory and USB export functionality, along with digital interfaces (RS232/RS485), the analyzer streamlines data collection and integration into existing control systems. Users benefit from real-time monitoring and convenient data access for reporting, validation, and regulatory compliance purposes.

User-Friendly Operation and Maintenance

Automatic calibration, easy-to-program alarms, adjustable calibration intervals, and a clear digital LCD display simplify operation and maintenance. Operators can rely on its 15-minute warm-up and straightforward extraction sampling method for consistent, accurate performance in demanding environments.

FAQ's of Continuous Gas Analyzer:

Q: How does the continuous gas analyzer operate for gas monitoring?

A: The analyzer uses an extractive sampling mode with non-dispersive detection techniques to continuously monitor gases such as O2, CO, CO2, NOx, and SO2. The sampled gas is analyzed in real time, providing continuous output and alarms if concentration limits are exceeded.

Q: What is the benefit of the programmable high/low alarm function?

A: The programmable alarm system allows users to set specific gas concentration thresholds, alerting operators to unsafe conditions or process deviations. This enhances safety, supports regulatory compliance, and facilitates early corrective actions.

Q: When should calibration be performed on this analyzer?

A: Calibration should typically be performed every 6 to 12 months; however, the interval is user adjustable to suit specific operational or regulatory requirements. Regular calibration ensures optimal accuracy and reliability of measurement.

Q: Where can the continuous gas analyzer be installed?

A: The analyzer can be panel- or wall-mounted in industrial, laboratory, or environmental monitoring settings. Its IP54-rated, powder-coated metal enclosure provides protection against dust and splashes, making it suitable for challenging operational environments.

Q: What output and communication options are available?

A: The system supports both analog (4-20 mA) and digital outputs, including RS232 and RS485 interfaces. This facilitates integration with various control and automation systems for streamlined process control and data management.

Q: How does the internal data logging and USB export support operations?

A: The built-in memory stores real-time measurement data, which can be easily exported via USB for further analysis or record-keeping. This feature simplifies compliance reporting and operational documentation.

Q: What are the operational limits for temperature, humidity, and gas pressure?

A: The analyzer operates within a temperature range of 5-45C and can handle 0-95% relative humidity (non-condensing). It requires a gas pressure of 0.2-0.5 MPa for optimal performance.
