Portable VOC Detector

Name: Portable VOC Detector
Brand: HNL SYSTEMS PVT. LTD.
Price: 95000 INR
Availability: InStock

Price 95000 INR/ Piece

Get a Price/Quote

MOQ : 2 Pieces

Portable VOC Detector Specification

Humidity
0-95% Rh

Temperature
Up to +55 Celsius (oC)

Test Range
0-1000 PPM

Weight
400 Grams (g)

Use
Multipurpose

Operating Voltage
6 V DC Volt (V)

Net Weight
400 Grams (g)

Portable VOC Detector Trade Information

Minimum Order Quantity
2 Pieces

Payment Terms
Telegraphic Transfer (T/T)

Supply Ability
4 Pieces Per Month

Delivery Time
1 Months

Main Export Market(s)
Eastern Europe, Western Europe, Middle East, Africa, Asia

Main Domestic Market
All India

Certifications
CE

About Portable VOC Detector

VOC gas monitor is meant to be used for VOC detection. Detection of leaks and poor air quality are essential to prevent health hazards. This quick responding instrument is highly sensitive and can be provided with optional accessories and capabilities, like internal pump, data logging and RS-232 output.

This instrument based on a microcontroller is highly sensitive to VOC and solvent vapor. The level of gas and vapors is displayed on LCD display. If the level reaches to a dangerous level, this quick to response instrument will alert the user through an audible alarm. When it is started, this instrument does a self integrity check and then get into measurement mode. The standard feature of VOC gas monitor are visual / audible alarms, auto calibration, back light LCD display, and software controlled alarm settings. This monitoring device has a data logger and digital output. It operates on a battery and therefore can be taken anywhere to trace leaks at their source. Customers can also opt for an optional inbuilt pump which will let them detect the leak from far away location or check the VOC concentration before entry.

Specification:

Target Gases / Vapors : Volatile Organic Compounds
Display : Alphanumeric LCD
Case : High Impact Plastic
Detector : Semiconductor
Sampling : i) Diffusion (D)
Suction (S)
Measuring Ranges : 0 - 25 PPM, 0 - 1000 PPM
Resolution : i) 1 PPM (Isobutylene calib) 0.1 PPM (Optional)
Power Source : Rechargeable Batteries
Temperature Range : 0°C to 55°C typical
Humidity Range : 0 to 90% RH (Non-Condensing)
Response Time : < 10 seconds
Dimensions : 157 x 84 x 30mm
Accessories : Leather Cover
Ni-Cad batteries
Charger 220V / 50Hz
Optional Features : Data logger and Digital output
Software RS 232,Probe and filter.

Partial Gas List

Acetone, Arsine, Ammonia, Benzene, Carbon Disulfide, Chlorobenzene, Isopropanol, Methylamine,Methyl Bromide, Methyl Ethyl Ketone, Dichlorobenezene, Dichloroethylene, Dioxane, Ethanol, Ethylbenzene, Ethylene Oxide, Ethyl Ether, Gasoline, Hexane, Hydrazine, Hydrozoic Acid HN3, isobutylene, Methyl Mercaptan, MTBE,Styrene, Tetrachloroethylene, Tetrahydrofuran, Toluene, Trichloroethylene, Trimenthylamine, Vinyl Acetate, Vinyl Bromide, Xylene, Dimenthyformamide, Phosphine, Naphtha

Note : Specifications and Features will vary with application. The above are established and validated during design, but are not to be construed as test criteria for every product. Due to HNL s commitment to research, design and product improvement, specifications are subject to change without notice

Efficient Multipurpose Detection

This portable VOC detector is designed to cater to a wide range of applications including industrial safety, indoor air quality assessments, laboratory monitoring, and fieldwork. Its lightweight structure and easy operation make it suitable for rapid, on-site detection of volatile organic compounds, ensuring safety and compliance in various settings.

Advanced Features and Durability

Equipped to measure VOC concentrations from 0 to 1000 PPM, the device operates efficiently in rigorous conditions-handling humidity up to 95% RH and temperatures as high as +55C. Its durable build and reliable performance provide consistent results, supporting critical environmental and workplace safety needs.

FAQ's of Portable VOC Detector:

Q: How is the Portable VOC Detector used for measuring volatile organic compounds?

A: The detector is switched on using its 6 V DC supply and positioned in the area where VOC levels need assessment. It provides real-time readings within the 0-1000 PPM range, allowing users to quickly identify and respond to hazardous gas concentrations.

Q: What environments are suitable for operating this device?

A: This portable detector is built for multipurpose use, including industrial sites, laboratories, indoor workplaces, and open environments. It maintains accurate performance in humidity from 0-95% RH and temperatures up to +55C, making it suitable for diverse conditions.

Q: When should I use a VOC detector in my facility?

A: A VOC detector should be used whenever there's a risk of chemical emissions, during equipment maintenance, after chemical spills, or as part of routine safety monitoring in areas where VOCs are present. Regular checks help maintain a safe and compliant environment.

Q: Where can this product be sourced from?

A: The Portable VOC Detector is manufactured and exported from India. As an experienced producer and supplier, we ensure quality standards for global clients across industrial, commercial, and research sectors.

Q: What is the process for calibrating the VOC detector?

A: Calibration involves exposing the detector to a known concentration of VOCs and adjusting its settings for accurate readings. This should be carried out periodically or as recommended in the device's manual to ensure consistent measurement accuracy.

Q: What are the benefits of using this VOC detector over stationary systems?

A: The portability and light weight (400 grams) of this detector enable rapid spot-checks and versatile usage across different locations, reducing downtime and providing immediate insights compared to fixed monitoring solutions.
